Detail CLAMSHELL BUCKET 6 M3 - HYDRAULIC GRAB
HYDRAULIC CLAMSHELL BUCKET 6 M3
BUCKET NEEDED FOR EXCAVATING BUILDING FOUNDATIONS AND DIGGING PITS.
Shell Push Type : Because the bucket is opened/closed with a hydraulic cylinder, penetration force is strong enough to make deep pit digging easier.
OVERALL DIMENSION :
Opened : 2060 x 3600 x 4046 mm.
Closed : 2060 x 3161 x 4756 mm.
TECHNICAL SPECIFICATION :
Excavator capacity : 25 T
Specific gravity : 1,5 – 2,5 T/M3
Volume (dome 30°) : 6,0 M3 = 15 T
Weight of empty : 8,0 T
Hydraulic capacity : 200 Bar
Hydraulic stoke : 900 mm.
MATERIAL SPECIFICATION :
Shell, Tie rod, Bracket, etc : SS 400
Shell edge : HARDOX 400
Bearing : Bushing Bronze
Pin, Axle : AISI 4140, 1045
Teeth : Cast Steel.
